Specifications:
All the parts/boilers are welded by qualified welders and will be pressure tested for leaks when it's finished, the system is rated at 0.1MPa.
Built from heavy gauge 304 stainless steel and t2 lead free 99.9% copper from big name manufacturers. Can provide certificates if needed.
Ideal for making moonshine, whiskey, vodka, gin, brandy, grappa etc.
Can produce up to 95abv alcohol.
Modular design so you can add many additional items to the system such as gin basket，copper helmet，extra sections etc.
Includes:
1） For the column:
4* 4" Copper sight glass tee with copper bubble plate
1* Copper 4" dephlegmator
1* Copper 4" to 2" reducer with dial thermometer
2* Copper 2" 90deg elbow
1* Copper 2" shotgun condenser
1* Copper parrot with sampling valve
With all the needed tri clamps, gaskets
2） For the boiler：
1*50Lt（13 gallons） stainless steel boiler
1*5.5Kw ulwd(ultra low watt density) heating elements
1* dial thermometer
1* 1" triclamp ball valve(drain)
1* 2" triclamp filling port with end cap
3）Red and blue water lines and push in fittings kit
4) Electric controller(Variable AMPs)
Note: This still comes with the controller but it needs to be wired by the customer, we can provide instructions on how to wire the controller.
Optional equipments(needs to be ordered separately):
Additional column sections(with copper bubble plate, clamp and gasket) add USD 150 each
4 inch gin basket add USD 180
4 inch copper helmet add USD 280
